Product Description Unit Model: SSR-40DA Terminal Type (Fotek original) Item size: 60*45*23mm Input Voltage: 4V to 32V DC Load Voltage: 24V to 380V AC Rated Load Current: 40A Trigger Current: 7.5mA/12V Operating Temperature: -20° to +80°C Housing Material: Intensive ABS Main Application: Industrial automation installment Computer periphery connection AC motor control Automatic fire control and security system Street light,signal light,traffic light,etc Specification Model: SSR-75DA (Fotek Original) Rated Current: 75A max I²t for fuse: 1328A²S Surge Current: 820A Peak Voltage: 1200VAC Output Voltage: 24 ~ 380VAC General Specification Input voltage: 4 ~ 32 VDC Turn off voltage: <3.5 VDC Trigger current: 12.0mA max. Control method: Zero cross Leakage current: 5 mA max. Response time: 8.3 ms (60Hz) Input immunity: 2 KV (EN61000-4-4) Isolation strength: 4 KVrms (EN60950/VDE0805) Insulation strength: 100M?/500VDC (EN60950/VDE0805) Housing material: (UL:94V0) Circumstance: -40°C ~ +80°C ; 35 ~ 85%RH
This Solid State Relay SSR-25DD can switch current loads of up to 25A with a 4-32V DC Input and a zero cross trigger control method. Each one of these relays is equipped with four screw terminals (for use with ring or fork connectors) and a plastic cover that slides over the top of the relay to protect the terminals.
Feature:
High Power Module
Long service life and high reliability
Highly reliable and compact sized
Designed to offer users maximum simplicity
Fast switching
Specification:
Model: SSR-25DD
Rated Current: 25A max.
Surge Current: 50A max.
Peak Voltage: 600VDC
Input Voltage: 4-32VDC
Output Voltage: 5-120VDC
Turn off Voltage: <3.0 VDC
Trigger Current: 12mA max.
Control Method: Random
Leakage Current: 1.0 mA
Response Time: 1.0ms
Input Immunity: 2 KV
Isolation Strength: 4 KVrms
Insulation Strength: 100M? / 500VDC
Circumstance: -40°C ~ + 80°C ; 35-85%RH Package included: 1 pcs Solid State Relay.
