SKU:MLE06283
Grove - Infrared Temperature Sensor
₱649.00
₱649.00
Sale
Sold out
Tax included.
Shipping calculated at checkout.
Loading locations...
files/MLE06283_3.jpg
04:11 PM
Couldn't load pickup availability
Product Description
Description:
This Grove-Infrared Temperature Sensor is a non-contact temperature-measuring model. The sensor is composed of 116 elements of thermocouple in series on a floating micro-membrane having an active diameter of 545μm and with a blackened surface to absorb the incident thermal infrared radiation, which induces a voltage response at output terminals.
Features:
Non-contact Temperature Measurement: Infrared temperature collection within 9cm
Wide Range of Temperature Measurements: Temperature measurements range from -10 to 100 ℃
Low Power Consumption: The power consumption is less than 0.6mW
Accurate Temperature Measurement: The measurement accuracy error was only ±2℃
Grove-compatible Interface: The product ensures "Plug and Play" and could be versatile for various applications of Grove
Specifications:
Dimensions: 130mm × 80mm × 11mm
Supply Voltage: 3.3V / 5V
Measuring Current Supply: 160 - 200 uA
Measuring Range: -10 ~ 100°C
Measuring Accuracy: ±2℃
Measuring Distance: 9cm
Holding Time: 2s
Operating Temperature: -10 ~ 80 °C
Storage Temperature: -35 - 80 °C
Application:
- Motion sensor
- Thief-guarding System
- Switch
- Industrial automation
- Body distance check
Documents:
Part List:
1x Grove - Infrared Temperature Sensor
