M5Stack NeoHEX 37 RGB LED Board (WS2812)

₱600.00 PHP
₱600.00 PHP
Sale Sold out
Tax included. Shipping calculated at checkout.
Or 3 months for only ₱1,000 with . Learn More.
Only 9 units left

About the Product

Neo-HEX is a hexagonal board with 37 RGB LED flexible beads and will be sure to 'WOW' plenty. Use single BUS control, and support multiple boards connecting. Two sets of different angle input connectors are provided for independent power supply + signal control. External structure with fixing ears for easy installation. With its opal light sheet, the diffusion creates a gentle glow and provides innovative solutions to transform your living spaces into unique pieces of functional art.
Product Features
Number of LEDs: 37
Support multiple boards connection
6x fixing ears (removable)
Comes with opal light sheet
Single pixel support 256 levels of brightness display, can be combined for 16777216 kinds of full color display
1x Neo-HEX Unit
1x Opal light sheet
1x Power Consumption Reference Card
1x HY2.0-4P cable (20cm)
Lighting decoration
Specification Parameters
LED Bead Model WS2812C-2020-V1
Number of light beads 37
Voltage supply 3.7 ~ 5.3V
Logic input level -0.3V ~ VDD+0.7
Output/output interface HY2.0-4P interface: 2x input (signal, power), 1x output (extension)
Refresh Rate 30 frames (1024 cascades)
Power consumption Actual measurement of power consumption (37 lights are fully lit, brightness 100%)?
Red Light?DC5V@207mA
Green Light?DC5V@109mA
Blue Light?DC5V@208mA
White light?DC5V@568mA
Adjustable brightness Level 256
Support Colors 16777216 kinds of colors
Fixing hole diameter 2mm
Net Weight 3.7g
Gross Weight 9g
Product Size 40*36*7mm
Package Size 93*138mm
