DFRobot Gravity: Non-contact Digital Water / Liquid Level Sensor For Arduino | SEN0204

Description:

Non-contact Digital Liquid Level Sensor

This Non-contact Digital Liquid Level Sensor utilizes advanced signal processing technology. This sensor uses a powerful chip (XKC-25-T12V) with high-speed operation capacity to achieve non-contact liquid level detection. No contact with liquid makes the module suitable for hazardous applications such as detecting toxic substances, strong acid, strong alkali and all kinds of liquid in an airtight container under high pressure.

The liquid level sensor is equipped with an interface adapter that makes it compatible with DFRobot "Gravity" interface. Four levels of sensitivity can be configured by pressing the SET button.

Specifications:

• Chip: XKC-Y25-T12V
• Interface: Gravity Digital
• Operating Voltage (InVCC): DC 5 ~ 24 V
• Current Consumption: 5 mA
• Output voltage (high level) : InVCC
• Output voltage (low level) : 0V
• Output current: 1 ~ 50 mA
• Response time: 500 ms
• Operating Temperature : 0 ~ 105 ?
• Range for thickness of induction (sensitivity): 0 ~ 13 mm
• Humidity: 5% ~ 100%
• Material: ABS.
• Waterproof performance: IP67
• Dimension : 28 * 28 mm / 1.1 * 1.1 inches

Documents:

• WIKI (Non-contact Liquid Level Sensor XKC-Y25-T12V SKU: SEN0204)
