SKU:MLE03351
M5Stack PIR Motion Sensor (AS312)
₱380.00
₱380.00
Sale
Sold out
Tax included.
Shipping calculated at checkout.
Or 3 months for only ₱1,000 with
. Learn More.
Only 2 units left
Couldn't load pickup availability
Share
About the Product
PIR is a human body infrared unit. It belongs to the "passive pyroelectric infrared detector". It detects the infrared radiation emitted and reflected by the human body or object. When infrared is detected, the output level is high and it takes a while. Delay (high during the period and allow repeated triggers) until the trigger signal disappears (restores low).
This Unit communicates with the M5Core via the GROVE B.
Notice: This Unit has 2s delay time.
Product Features
- Detects the distance: 500cm
- latency time: 2s
- Sensing range: < 100°
- Quiescent current: < 60uA
- Operating temperature: -20 - 80 °C
- GROVE interface, support UIFlow and Arduino
- Two Lego installation holes
Include
- 1x PIR unit
- 1x GROVE Cable
Applications
- Human body Induction Lamp
- Security Product
- Automatic Induction Appliance Settings
Specification
Resources | Parameter |
---|---|
Net weight | 5g |
Gross weight | 20g |
Product Size | 32*24*12mm |
Package Size | 60*57*17mm |
