RS PRO 4 Core Power Cable, 6 mm², 50m, Black PVC Sheath, NYY-J, 1 kV, 600 V

RS PRO 4 Core Power Cable, 6 mm², 50m, Black PVC Sheath, NYY-J, 1 kV, 600 V

In stock

SKU:MLE04530

Regular price ₱44,500.00
Regular price Sale price ₱44,500.00
-Liquid error (snippets/price line 90): divided by 0% OFF Sold out
Shipping calculated at checkout.
Or 3 months for only ₱1,000 with . Learn More.
View full details

Product Details

RS PRO NYY-J Mains Power Cable


From RS PRO a high-quality NYY-J mains power cable also known as a power control cable with a PVC outer sheath and a nominal voltage rating of 600/1000V. This durable and cost-efficient mains cable is used for the electrical energy supply in fixed wiring installations both indoors and outdoors. The cable can be directly buried under the ground, in brickwork, in concrete as well as submerged under water for a limited period of time.

Cable Construction

This electrical mains power cable consists of cores made up of IEC 60228 class 1 solid copper conductors. Each individual core is surrounded by colour coded PVC (Polyvinyl Chloride) insulation for easy identification of the wires. The cores are then surrounded by a final outer layer of a tough PVC called a sheath or jacket. This power cable also has a filler compound which fills the gaps between the cores and the outer sheath to give the cable a round shape.

Features and Benefits

• Flame retardant to IEC 60332-1 & EN 50265-2-1
• Mechanically tough, durable and resistant to abrasion
• UV and weather resistant
• Lightweight
• Good electrical and insulation properties
• Corrosion resistant and rustproof
• Cost effective due to long cable lifespan

Technical Datasheets

Specifications

Attribute Value
Cross Sectional Area 6 mm²
Number of Cores 4
Sheath Colour Black
Length 50m
Cable Type NYY-J
Sheath Material PVC
Voltage Rating 1 kV, 600 V
Conductor Strand Type Solid
Size of Strands 2.69 mm
Maximum Operating Temperature +70°C
Conductor Material Copper
Standards Met EN 50265-2-1, IEC 60228 Class 1, IEC 60332-1, IEC 60502-1, RoHS Compliant
Insulation Material PVC
Conductor Resistance 3.08 Ω/km
Fire Behaviour Flame Retardant
Minimum Operating Temperature -5°C
