. Gauge Size: 24
Strand Diameter: 0.08mm
Insulation Thickness/Material: 0.2mm/Silicone
Conductor Diameter/Material: 0.58mm/Tinned copper
Outer Diameter: 1.6mm
Conductor Resistance: 91.6 Ω/km
Rated Voltage: 600 V
Rated Temperature: 200 degrees Celsius
Applications: Model airplanes, RC toys, Remote Control, Electronic, Battery Cable, drones, DIY, etc
Wire Size: 22 AWG
Rated Voltage: 600V
Rated Temperature: -60oC - 200oC
Conductor: Tinned Copper
Copper Diameter: 60mm x 0.08mm
Diameter: 0.8mm
Coating Thickness: 0.45mm
Outside Diameter: 1.7mm
Resistance: 88.6 Ω/km
Cross-sectional Area: 0.3mm2
Withstand Current: 8.43A
Weight: 5.5 g/m
Wire Size: 20 AWG
Voltage Rating(V ): 600 V
Core Type:Stranded
Cable Length (cm): 700
Weight(g): 310
Shipping Weight 0.43 kg
Shipping Dimensions 14 × 7 × 7 cm
Core Dimension 18 AWG / Solid
Strand Diameter 1mm
Core Material Tinned Copper
Voltage Rating 600V
Temperature Rating -55 -105 degrees Celsius
Wire Length 5m per color
Overall Wire Diameter 1.95mm
