DC-DC Boost Converter LM2577 / XL6009

DC-DC Boost Converter LM2577 / XL6009

In stock


Regular price ₱50.00
Regular price Sale price ₱50.00
Sale Sold out
Shipping calculated at checkout.
Or 3 months for only ₱1,000 with . Learn More.
View full details

DC-DC Boost Converter LM2577

Finding power supplies for your project can be quite difficult and time consuming, particularly if your project requires a number of components with varying voltages, The DC-DC Boost Converter LM2577 solves this by converting lower voltage to a higher voltage without the need for an additional power supply.

This DC to DC boost converter LM2577 module is based on TI LM2577 Step-up Voltage Regulator. The LM2577 series of regulators are monolithic integrated circuits that provide all the active functions for a step-up switching regulator, capable of driving a 3A load with line and load regulation.

The Maximum power dissipation of 10 Watts can be increased with the addition of heatsink.

If you are looking to decrease or step-down the voltage, we have the DC-DC Buck Converter LM2596S.



  • Input voltage: 3V-34V
  • Output voltage: 4-35V
  • Input Current: 3A (MAX)
  • Output Current: 2.5A (MAX)
  • Maximum Power Dissipation: 10 Watts
  • Module size: 50 mm x25 mm
