About the Product
Description:
UHF-RFID is an embedded wireless radio frequency reader module operating in the ultra-high frequency (UHF) range. It utilizes the JRD-4035 module solution, which includes a built-in ceramic antenna. This eliminates the need for users to equip additional antennas, providing a more convenient and reliable solution.
The module is optimized for RF design, ensuring low power consumption and high performance. With a transmission power of 100mW, it can achieve an effective reading distance of more than 1.5 meters. This allows for efficient and reliable reading of UHF RFID tags within the module's range.
UHF-RFID module communicates via a serial interface and is compatible with a built-in encapsulated AT command set. This enables plug-and-play functionality and simplifies the development and integration process. The module provides a user-friendly experience for both development and usage.
UHF-RFID module is well-suited for various application scenarios, including warehousing logistics management and smart retail. In warehousing logistics, it enables efficient tracking and management of inventory and assets. In smart retail, it can be used for inventory management, anti-theft systems, and customer engagement. The module can handle multiple product tags simultaneously, meeting the requirements of monitoring and reading multiple RFID tags in different applications.
Features:
- Stable recognition distance: 1.5m-2m
- Working spectrum range: 840-960MHz
- Air interface protocol: EPCglobal UHF Class 1 Gen 2, ISO 18000-6C
- UART communication interface (baud rate: 115200bps)
- The buffer area can hold up to 200 tags
- Tag recognition is sensitive and stable
Specifications:
- Unit Code: (JRD-4035) | U107
- Air interface protocol: EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
- Work area support: US, Canada and other regions following U.S.FCC. Europe and other regions following ETSI EN 302 208, Mainland China, Japan, Korea, Malaysia, Taiwan
- Working spectrum range: 840-960MHz
- Output power range: 18-26 dBm
- Tag cache area: 200 tags
- Communication protocol: UART (Baud rate: 115200bps)
- Net weight: 41g
- Gross weight: 58.8g
- Product size: 56*48*11.5mm
- Package size: 88*61*21mm
- Shell material: Plastic (PC)
Applications:
- Warehouse logistics pallet management
- Vehicle management
- Smart retail
Part List:
- 1x UHF-RFID
- 1x HY2.0 cable (5CM)
Model Size:
